RV207 Compatible Replacement Camera with adaptor - REVERSING CAMERA ONLY
For more than a decade we have supported the replacement of parts that fail on the Swift, Bessacarr, Autotrail reversing camera systems originally produced by Sargent Electrical. This listing is to replace the the driving camera only from the twin system that was fitted on numerous models.
For more than a decade we have supported the replacement of parts that fail on the Swift, Bessacarr, Autotrail reversing camera systems originally produced by Sargent Electrical. This listing is to replace ONLY the reversing camera on the twin camera system that was fitted on numerous models.
We will supply the correct adaptors for this camera system to convert our 4 pin version in to their 6 pin PS/2 connector version.
The downward facing reverse camera has a wide angle lens fitted. The adaptor will have a wire tail coming off the connector. This must be joined (solder/crimp/wago) to the orange colour lead that goes to the original camera. This orange lead is the reversing +12V trigger, which feeds down one of the 6 pins to tell the EM5 series box at the front of the vehicle when you are in reverse.
The reversing camera will fit to the original bracket fitted. The cameras do squeeze in, slightly tighter fit than the original - but a small bit of pressure when inserting allows them to click in.
Rest assured that we have supplied many hundreds of these with the adaptors to many happy customers.
Image Device:1/3 SONY 811 CCD 960H 700TVL
TV System: PAL
Effective Pixels: 976*582
Apect Ratio of output: 4:3
Scanning System: 2:1 Interlace
Sync. System: Internal
Resolution: 700 TV lines
Minimum Illumination:0 Lux (IR LEDs on)
Waterproof to Ip68
Infrared LEDs to provide night view
120-degree lens
Mirror image
Stainless Steel Bracket (painted)
